| Details | |
|---|---|
| Work Holding and Operation | Collet Chuck 42mm - Hydraulic |
| Maximum Chucking Size | Ø42mm X 500mm LONG |
| Maximum Machining Length | 180mm Max |
| Maximum Size of Polygon | A/F 40mm |
| Spindle Speed Ratio | 1:1 ~ 1:99 Electronic |
| Work Spindle Nose Type and Size | DIN A2-5 |
| Work Spindle Motor | 4.78nm / 2,000 rpm |
| Work Spindle Drive | 4.78nm / 2,000 rpm |
| Z Axis Stroke - Drive | 225mm - Servomotor |
| X Axis Stroke - Drive | 180mm - Servomotor |
| Y Axis Stroke - Drive | 50mm - Servomotor |
| Pos Accuracy and Repeatability | 10 Microns |
| Feed Rate | 0.01 ~ 0.5mm Per Rev |
| Rapid Travel Rate | 10 Mtrs Per Min |
| Centralized Lubrication | 0.09 kw |
| Coolant Pump | 0.10kw |
| Control Voltage | 220 vac/24 vdc |
| Main Power Supply | 3 Phase, 415vac ±10% 50hz |
| Total Connected Load | 5.95 kw (8hp) |
| Floor Area LXWXH | 1.8m X 1.9m X 2.1m |
| Nett Weight | 2200 kgs |
| Gross Weight | 2450 kgs |
